G121X1-L02 Innolux 12.1 inch 1024x768 lcd panel Backlight 500nits LVDS applied

Chimei Innolux G121X1-L02 Application DetailsBasic Detail :Panel BrandINNOLUX CHI MEIModel NameG121X1-L02Panel Typea-Si

Model	G121X1-L02
Brand	Chimei Innolux
Size	12.1inch
Resolution	1024×768
Brightness	500cd/m2
Perspective	80/80/80/80
Interface	LVDS
Operating Temp	-30 ~ 80 °C
Production State	Discontinued

Click For Price

Chimei Innolux G121X1-L02 Application Details

Basic Detail :	Panel Brand	INNOLUX/CHI MEI	Model Name	G121X1-L02
	Panel Type	a-Si TFT-LCD , LCM	Another Name
	Panel Size	12.1”	Designed For	Industrial,Automotive Display
Maximum Ratings :	OP Temperature	-30 ~ 80 °C	ST Temperature	-30 ~ 85 °C
Maximum Ratings :	RoHS	RoHS	Vibration Level	1.5G (14.7 m/s²)
Features :	Wide Temperature，Lamp Repaceable, Life>=50K hours,Glossy

Chimei Innolux G121X1-L02 Optical Details

Basic Information :	Luminance	500 cd/m²(Typ.)	Contrast Ratio	700:1 (Typ.) (Transmissive)
	Good View at	-	Response Speed	6/17 (Typ.)(Tr/Td) ms
	Viewing Angle	80/80/80/80 (Typ.)(CR≥10)	Operating Mode	TN, Normally White, Transmissive
Color Performance :	Chromaticity	Wx:0.308; Wy:0.318	Display Colors	262K (6-bit)
Color Performance :	Color Temperature	6879K	White Variation	1.25/1.40 (Typ./Max.)(5 points)
1931 Color Gamlt :	NTSC Ratio	46%	sRGB	64% coverage
	Adobe RGB	48% coverage	DCI-P3	48% coverage
	Rec.2020	34% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

Chimei Innolux G121X1-L02 Mechanical Details

Pixel Features :	Number of Pixel	1024(RGB)*768, XGA	Arrangement	RGB Vertical Stripe
Pixel Features :	Dot Pitch (W*H)	0.080*0.240 mm	Pixel Pitch (W*H)	0.240*0.240 mm [105PPI]
Physical Size :	Active Viewing(mm)	245.76(W)*184.32(H) mm	Bezel Area (mm)	249.0(W)*187.5(H) mm
Physical Size :	Outline Dim.(mm)	260.5(W)*204(H) mm	Depth(mm)	12.2±0.5 mm
Outline Features :	Form Style	Flat Rectangle	Outline Shape
Outline Features :	Aspect Ratio	4:3(W:H)	Orientation	Landscape type
Fixation :	Side mounting holes (4-M2) on left, right bezel
Other Spec :	Weight	700g (Max.)	Surface	Glare (Haze 0%), Hard coating (3H)

Chimei Innolux G121X1-L02 Electronics Details

Refresh Rate :	60Hz
Reverse Scan :	No

Chimei Innolux G121X1-L02 Interface Details

Signal Systerm :		LVDS (1 ch, 6-bit)				Logic Voltage				-
Signal Electrical :	Voltage Input			3.3V (Typ.)			Current Input		510mA (Typ.)
	Consumption			1.68W (Typ.)
Interface Features :	Position			-			Physical Type		Connector
Interface Detail :	Brand		Model		Pin Pitch			Pins	Amount		Pin Assignment
	JAE		FI-SEB20P-HFE		1.25mm			20pins	1 pcs		LVDS-20P1C6B-070A

Chimei Innolux G121X1-L02 Backlight Details

Lamp Features :	Lamp Type		CCFL		Quantity	2 pcs		Position	Edge light type (Top and Bottom)
	Exchange		Replaceable		Lamp Shape	Straight		Lamp Life	50K(Min.) (Hours)
Lamp Electrical :	Input Voltage		500±50V		Input Current	2.0/8.0/8.5mA (Min./Typ./Max.)
	Frequency		45/80KHz (Min./Max.)		Turn-on Voltage	-
	Consumption		8.0W (Typ.)
Interface Features :	Position		-		Physical Type	Connector
Interface Detail :	Brand	Model		Pin Pitch	Pins		Amount		Pin Assignment
	JST	BHR-03VS-1		4.0 mm	3 pins		2 pcs		BLL-3PINS-HNL
Backlight Driver :	No

Chimei Innolux G121X1-L02 Carton Details

Package Box :	Amount	Weight	Size (LWH)
Package Box :	15pcs / box	11.15 Kgs	461362314 mm
