G101ICE-L01 Chimei Innolux display 10.1 Inch 1280*800 tft lcd display screen

Chimei Innolux G101ICE-L01 Application DetailsBasic Detail :Panel BrandINNOLUX CHI MEIModel NameG101ICE-L01Panel Typea-S

Model	G101ICE-L01
Brand	Chimei Innolux
Size	10.1inch
Resolution	1280*800
Brightness	500cd/m2
Perspective	85/85/85/85
Interface	LVDS
Operating Temp	-20 ~ 70 °C
Production State	In Production

Click For Price

Chimei Innolux G101ICE-L01 Application Details

Basic Detail :	Panel Brand	INNOLUX/CHI MEI	Model Name	G101ICE-L01
	Panel Type	a-Si TFT-LCD , LCM	Another Name
	Panel Size	10.1”	Designed For	Industrial
Maximum Ratings :	OP Temperature	-20 ~ 70 °C	ST Temperature	-25 ~ 70 °C
Maximum Ratings :	RoHS	RoHS	Vibration Level	1.5G (14.7 m/s²)
Features :	WLED Backlight，Life>=50K hours,With LED Driver, 6/8 bit,Matte

Chimei Innolux G101ICE-L01 Optical Details

Basic Information :	Luminance	500 cd/m²(Typ.)	Contrast Ratio	800 : 1 (Typ.) (Transmissive)
	Good View at	Symmetry	Response Speed	14/11 (Typ.)(Tr/Td) ms
	Viewing Angle	85/85/85/85 (Typ.)(CR≥10) 0)	Operating Mode	AAS, Normally Black, Transmissive
Color Performance :	Chromaticity	X:0.313; Y:0.329	Display Colors	262K/16.2M (6-bit / 6-bit + FRC)
Color Performance :	Color Temperature	6485K	White Variation	1.43 (Max.)(5 points)
1931 Color Gamlt :	NTSC Ratio	54%	sRGB	75% coverage
	Adobe RGB	56% coverage	DCI-P3	56% coverage
	Rec.2020	40% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

Chimei Innolux G101ICE-L01 Mechanical Details

Pixel Features :	Number of Pixel	1280(RGB)*800, WXGA	Arrangement	RGB Vertical Stripe
Pixel Features :	Dot Pitch	0.05650.1695 (HV)	Pixel Pitch (W*H)	0.16950.1695 (HV) [149PPI]
Physical Size :	Active Viewing(mm)	216.96(H) *135.6(V)	Bezel Area (mm)	218.96(H) *137.6(V)
Physical Size :	Outline Dim.(mm)	230.7(H) *152.55(V)	Depth(mm)	6.5±0.5 mm
Outline Features :	Form Style	Flat Rectangle	Outline Shape
Outline Features :	Aspect Ratio	16:10 (W:H)	Orientation	Landscape type
Fixation :	Side mounting holes (4-M2) on left, right bezel
Other Spec :	Weight	360/375g (Typ./Max.)	Surface	Antiglare, Hard coating (3H)

Chimei Innolux G101ICE-L01 Electronics Details

Refresh Rate :	60Hz
Reverse Scan :	No
Total Consumption :	6.18W (Typ.)

Chimei Innolux G101ICE-L01 Interface Details

Signal Electrical :	Voltage Input		3.3V (Typ.)		Current Input		265/320mA (Typ./Max.)
	Consumption		-		Signal Interface		LVDS (1 ch, 6/8-bit)
Interface Features :	Position		-		Physical Type		Connector
Interface Detail :	Brand	Model		Pin Pitch		Pins	Amount	Pin Assignment
	I-PEX	20455-040E-12		0.5mm		40pins	1 pcs

Chimei Innolux G101ICE-L01 Backlight Details

Lamp Features :	Lamp Type	WLED		Quantity		-	Position		Edge light type
	Exchange	-		Lamp Shape		Array	Lamp Life		50K(Min.) (Hours)
Interface Features :	Position	-		Physical Type		Included in panel signal interface
Backlight Driver :	With LED Driver
Driver Electrical :	Input Voltage		12.0V (Typ.)		Input Current			0.42/0.50A (Typ./Max.)
	Consumption		5.0/5.8W (Typ./Max.)

Chimei Innolux G101ICE-L01 Carton Details

Package Box :	Amount	Weight	Size (LWH)
Package Box :	28pcs / box	12.02 Kgs	435350275 mm
