15inch 4-wire resistance touch screen AMT9102

model

9102

Brand

AMT

Size (inches)

15.0inch

OVERALL THICKNESS :

2.10±0.20mm

Tail Design

FPC / AMP-C

Outline(mm)

330.00 x 254.00

Active Area(mm)

304.10 x 228.10

ITO GLASS THICKNESS :

1.80mm

FRONT SUREACE

ANTI-CLEAR HARDCOAT

LAYER TO LAYER ASSEMBLY TOLERANCE

+0.50mm

TAIL TYPE

HSC WITH CONNECTOR

OTHER SPEC

SEE APPROVAL SHEET

CONNECTOR AND PINOUT AS INDICATED，*BEFORE DESIGN PLEASE REFER TO THE INTEGRATION GUIDE
