1、BOE DV220X2M-NV0 Application DetailsBasic Detail :ManufacturerBOEModel NameDV220X2M-NV0Panel Typea-Si TFT-LCD , LCMPa
| Model | DV220X2M-NV0 |
| Brand | BOE |
| Size | 22.0inch |
| Resolution | 1920*1920 |
| Brightness | 500cd/m2 |
| Perspective | 89/89/89/89 |
| Interface | LVDS |
| Operating Temp | 0 ~ 50 °C |
| Production State | In Production |
Hangzhou IDT DISPLAY TECHNOLOGY CO.,LTD is the main agent of Youda AUO LCD screen, CHIMEI LCD screen, Mitsubishi LCD screen, INNOLUX LCD screen, Tianma LCD screen, touch LCD screen and other small ...
Read More
1、BOE DV220X2M-NV0 Application Details
Basic Detail :
Manufacturer
BOE
Model Name
DV220X2M-NV0
Panel Type
a-Si TFT-LCD , LCM
Panel Size
22.0inch
Designed For
Digital Signage
Maximum Ratings :
OP Temperature
0 ~ 50 °C
ST Temperature
-20 ~ 60 °C
RoHS
RoHS
Vibration Level
-
Features :
Industria，Digital Signage，Video Wall
2、BOE DV220X2M-NV0 Mechanical Details
Pixel Features :
Number of Pixel
1920(RGB)×1920
Arrangement
RGB Vertical Stripe
Dot Pitch (H×V)
0.0685×0.2055 mm
Pixel Pitch (H×V)
0.2055×0.2055 mm [123PPI]
Physical Size :
Display Area (H×V)
394.56×394.56 mm
Bezel Opening (H×V)
398.56×398.56 mm
Overall Dimension (H×V)
409.56×409.56 mm
Depth(mm)
7.6/12.6 (Typ./Max.) mm
Outline Features :
Form Shape
Flat Rectangle
Orientation
Landscape type
Aspect Ratio(W:H)
1:1 (H:V)
Videowall Seam
15.0 mm (Active to Active)
Other Detail :
Mass
1.96±0.10Kgs
Surface
Antiglare (Haze 25%), Hard coating (3H)
Holes & Brackets :
Rear mounting Pole (12-M3)
3、BOE DV220X2M-NV0 Optical Details
Basic Information :
Luminance
500 cd/m² (Typ.)
Contrast Ratio
1000:1 (Typ.) (Transmissive)
Good View at
Symmetry
Response Speed
8 (Typ.)(G to G) ms
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Operating Mode
ADS, Normally Black, Transmissive
Color Performance :
Color Temperature
Support Color
Color Coordinate
9969K
16.7M (8-bit)
X:0.280; Y:0.290
1931 Color Gamut :
NTSC Ratio
74%
sRGB
96% coverage
Adobe RGB
75% coverage
DCI-P3
77% coverage
Rec.2020
56% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
Luminance Variation :
1.33 (Typ.)(9 points)
4、BOE DV220X2M-NV0 Electronics Details
Refresh Rate :
60Hz
Reverse Scan :
No
Power Consumption :
22.3/26.7W (Typ./Max.)
5、BOE DV220X2M-NV0 Interface Details
Signal Electrical :
Input Current
1.2/1.8A (Typ./Max.)
Input Voltage
5.0V (Typ.)
Consumption
5.5/7.7W (Typ./Max.)
Signal Interface
LVDS (4 ch, 8-bit)
Interface Features :
Position
-
Physical Type
Connector
Interface Detail :
Brand
Model
Pin Pitch
Pins
Amount
Pin Assignment
UJU
IS050-C51B-C39
0.5mm
51 pins
1 pcs
6、BOE DV220X2M-NV0 Lightting Details
Lamp Features :
Lamp Type
WLED
Amount
13S4P
Position
Edge light type (Right side)
Exchange
-
Lamp Shape
4 strings
Lamp Life
30K(Min.)
WLED Electrical :
Input Voltage
37.7±1.3V
Input Current
115mA (Typ.)
Power Consumption
17.3/17.9W (Typ./Max.)
Interface Features :
Position
Down left corner
Physical Type
Connector
Interface Detail :
Brand
Model
Pitch
Pins
Quantity
Pin Configuration
3707K-X06X-08X
6pins
1 pcs
BLE-6PINS-CCAACC
Backlight Driver :
No
7、BOE DV220X2M-NV0 Packing Details
Box/Package
Pcs/Package
Package LWH (mm)
G.W (kgs)
10
495×318×495
N/A
