1、AUO G150XTN06 5 Application DetailsBasic Detail :ManufacturerAUOModel NameG150XTN06 5Panel Typea-Si TFT-LCD , LCMPane
| Model | G150XTN06.5 |
| Brand | AUO |
| Size | 15inch |
| Resolution | 1024*768 |
| Brightness | 300cd/m2 |
| Perspective | 80/80/70/80 |
| Interface | LVDS |
| Operating Temp | -20 ~ 70 °C |
| Production State | Discontinued |
Hangzhou IDT DISPLAY TECHNOLOGY CO.,LTD is the main agent of Youda AUO LCD screen, CHIMEI LCD screen, Mitsubishi LCD screen, INNOLUX LCD screen, Tianma LCD screen, touch LCD screen and other small ...
Read More
1、AUO G150XTN06.5 Application Details
Basic Detail :
Manufacturer
AUO
Model Name
G150XTN06.5
Panel Type
a-Si TFT-LCD , LCM
Panel Size
15.0 inch
Designed For
Industrial
Maximum Ratings :
OP Temperature
-20 ~ 70 °C
ST Temperature
-20 ~ 70 °C
Vibration Level
1.5G (14.7 m/s²)
RoHS
RoHS
Features :
WLED Backlight，Life>=50k hours,With LED Driver,Upside I/F,6/8 bit，Matte
2、AUO G150XTN06.5 Optical Details
Basic Information :
Luminance
300 cd/m² (Typ.)
Contrast Ratio
800 : 1 (Typ.) (Transmissive)
Good View at
-
Response Speed
5.7/2.3 (Typ.)(Tr/Td) ms
Viewing Angle
80/80/70/80 (Typ.)(CR≥10)
Operating Mode
TN, Normally White, Transmissive
Color Performance :
Chromaticity
Wx:0.311; Wy:0.322
Operating Mode
262K/16.2M (6-bit / 6-bit + FRC)
Color Temperature
6658K
White Uniformity
1.25/1.33 (Typ./Max.)(9 points)
1931 Color Gamut :
NTSC Ratio
64%
sRGB
85% coverage
Adobe RGB
66% coverage
DCI-P3
66% coverage
Rec.2020
47% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
3、AUO G150XTN06.5 Mechanical Details
Pixel Features :
Number of Pixel
1024(RGB)×768, XGA
Arrangement
RGB Vertical Stripe
Dot Pitch(W×H)
0.099×0.297 mm
Pixel Pitch(W×H)
0.297×0.297 mm [85PPI]
Physical Size :
Active Viewing
304.128(W)×228.096(H) mm
Overall Dim.
326.5(W)×253.5(H) mm
Bezel Opening
307.4(W)×231.3(H) mm
Overall Depth
12.0 (Max.) mm
Outline Features :
Form Shape
Flat Rectangle
Orientation
Landscape type
Aspect Ratio(W:H)
4:3
Shape Style
Holes & Brackets :
Side mounting holes (4-M3) on left, right bezel
Other Features :
Weight
1.25Kgs (Typ.)
Surface
Antiglare
4、AUO G150XTN06.5 Electronics Details
Frame Frequency :
60Hz
Reverse Scan :
No
Power Consumption :
7.9W (Typ.)
5、AUO G150XTN06.5 Backlight Details
Back-light Features :
Lamp Type
WLED
Amount
-
Life Time
50K(Min.) Hours
Replacement
No
Lamp Shape
-
Position
Edge light type (Bottom side)
Interface Features :
Type
Connector
Position
-
Lamp Driver
With LED Driver
Interface Detail :
Brand
Model
Pin Pitch
Pins
Amount
Configuration
E&T
3808K-F05N-12R
1.25 mm
5 pins
1 pcs
Driver Electrical :
Voltage Input
12±1.2V
Current Input
0.45A (Typ.)
Consumption
5.4W (Typ.)
6、AUO G150XTN06.5 Interface Detail
Signal Electrical :
Input Current
450/750mA (Typ./Max.)
Input Voltage
3.3V (Typ.)
Consumption
1.485/2.475W (Typ./Max.)
Signal Interface
LVDS (1 ch, 6/8-bit)
Interface Features :
Position
Upper middle of panel
Type
Connector
Interface Detail :
Brand
Model
Pitch
Pins
Amount
Pin Assignment
STM
MSB240420E
1.25 mm
20 pins
1 pcs
LVDS-20P1C8B-135A
7、AUO G150XTN06.5 Packing Details
Package Box :
Amount
Weight
Size (L×W×H)
15 pcs / box
20.0 Kgs (Max.)
434×380×353 mm
