IDT-G156QFH-01 is a 15 6-inch full view IPS LCD screen with IPS display module, ultra wide viewing angle, high contrast, resolution of 1920 × 1080, brightness of 250cd m2, supporting eDP communication interface, and can be used for white goods such as touch screen speakers and smart washing machines
| Model | IDT-G156QFH-01 |
| Brand | IDT |
| Size | 15.6inch |
| Resolution | 1920*1080 |
| Brightness | 250cd/m² |
| Perspective | 80/80/80/80 |
| Interface | eDP |
| Operating Temp | -10 ~ 50 °C |
| Production State | In Production |
Hangzhou IDT DISPLAY TECHNOLOGY CO.,LTD is the main agent of Youda AUO LCD screen, CHIMEI LCD screen, Mitsubishi LCD screen, INNOLUX LCD screen, Tianma LCD screen, touch LCD screen and other small ...
Read More
Feature
Specification
Model
IDT-G156QFH-01
Brand
IDT
Size
15.6inch
Resolution
1920 × 1080
Pixel pitch
0.17925(W)x 0.17925(H)mm
Display Mode
IPS/NB
Viewing Direction
ALL o'clock
Gray Scale Inversion Direction
ALL o'clock
28
250 cd/m2
LCM (W * H * D)
350.76X216.39X2.90mm
Active Area (W * H )
344.16X193.59mm
With /Without TP
Without TP
LED Numbers
9S5P-LED
Operation temperature
-10~+50℃
Storage temperature
-20~+60℃
Interface
eDP
LCM Power Supply
3.3V
LED Power Supply
27.0V
LCM Driver IC
-
Display color
16.7M
